KL Sons Pvt Ltd is proud to pioneer the production of medium and heavy hot rolled Universal beams and column sections in India. These sections are cost-effective, flexible and are superior in terms of strength, efficiency, higher axial and bending load-bearing capacities.Produced as per various International standards, these parallel flange beams and columns enable complex fabrications in high volumes due to inherent functional advantages.
U-Beam/U-Column | Mass M(kg/Mtr) | D (mm) | B (mm) | Flange | T (mm) | t (mm) |
UB-254X146X31 | 31.100 | 251.4 | 146.1 | 90 | 6 | 8.6 |
UB-254X146X37 | 37.000 | 256 | 146.4 | 90 | 6.3 | 10.9 |
UB-305X165X40 | 40.300 | 303.4 | 165 | 90 | 6 | 10.2 |
UB-305X165X46 | 46.100 | 306.6 | 165.7 | 90 | 6.7 | 10.8 |
UC 152X152 | 23.000 | 152 | 152 | 90 | 5.8 | 6.8 |
UB-203x133x30 | 30.000 | 206.8 | 133.9 | 90 | 6.4 | 9.6 |
UC-203x203x46 | 46.100 | 203.2 | 11 | 90 | 7.2 | 11 |
UC-254x254x73 | 73.100 | 254.1 | 254 | 90 | 8.6 | 14.2 |
